Scan Code In-Car Device

: Overview

The scan code in-car device (B503) uses an ARM Cortex-A7 processor and runs on the Linux 4.1 smart operating system. It integrates "card flash payment" and "QR code payment" functions, providing users with a smart POS terminal that offers a multi-channel payment experience.

Product performance advantages

Smart System

Linux 4.1 system, stable and reliable.
01
Dual-screen Display

4.3-inch + 0.4-inch dual screens. 4.3-inch color main screen, resolution 480*272; 0.4-inch four-digit LED secondary screen.
02
Scanning

Equipped with a hardware decoding module and independent scanning compartment for fast and accurate recognition and support of payment codes and offline codes.
03
State Secret Algorithm

The dedicated state secret algorithm chip ensures secure data storage and transmission.
04
Customizable Charging Modes

Current consumption mode can be set through the platform or a small keyboard, such as fixed amount or variable amount.
05
Segmented Billing Functionality

Uses GPS positioning to identify boarding and alighting points, enabling automatic segmented billing.
06

Usage scenario

Technical Parameter

Display

Dual-screen display: 4.3-inch color main screen, resolution 480*272; 0.4-inch four-digit LED secondary screen.
Communication Methods

Standard 4G, optional CAN, RS232.
Operating System

Linux 4.1
Contactless Card Reader

Supports M1 and CPU contactless cards
Keypad

Four function keys and one power switch button
Product Dimensions

240*150*65(mm*mm*mm)
QR Code Scanning

Supports QR code decoding.
Storage Capacity

2Gb DDR+8GB EMMC

success cases
