Wall-Mounted Large-Screen Card Swipe and QR Code Payment Terminal

: Overview

The wall-mounted large-screen card swipe and QR code payment terminal (A811) integrates a 7-inch touchscreen, a 3.5-inch color screen, a 13.56MHz RF card reader, a mechanical keyboard, QR code scanning, WiFi/Bluetooth, 4G, voice amplifier, TCP/IP, battery power supply, and other modules. Based on a smart operating system, it integrates "card flash payment" and "QR code payment" functions to provide users with a more user-friendly smart POS terminal.

Product performance advantages

Touchscreen Design

Multi-touchscreen design allows both parties involved in the transaction to interact with the amount and password, catering to different scenario requirements.
01
Scan Code Camera

Supports fast and accurate recognition and payment of various QR codes, including payment codes and offline codes.
02
Contactless Card Reader

Contactless Card Reader Supports ISO/IEC14443 standard for M1 and CPU contactless cards, compatible with Type A/B standards
03
Communication Methods

Supports TCP/IP, WiFi, Bluetooth, and 4G.
04
Dual Offline Payments

In the event of a network outage, it is still possible to make card swipe and QR code payments.
05
Large Capacity Battery

Equipped with a standard large-capacity lithium battery, supports 2-4 hours of operation during power outages.
06

Usage scenario

Technical Parameter

Dual-screen Display

7-inch main screen, 3.5-inch color rear screen.
Wireless Communication

Optional 4G, dual-band WiFi, Bluetooth 4.0.
Contactless Card Reader

Contactless Card Reader Supports ISO/IEC14443 standard for M1 and CPU contactless cards, compatible with Type A/B standards
QR Code Scanning

Supports QR code decoding
Keypad

10 numeric/letter keys, 6 function keys, 1 power switch button, 1 cancel key, 2 confirm keys.
SAM Card Slot

3 PSAM card slots; 1 SIM card slot.
Physical Interfaces

1 USB, 1 Micro USB, 1 RJ45, 1 RJ11.
Product Dimensions

250*214*88 (mm).
